CNC Frezen

CNC Frezen

CNC frezen van complexe freesdelen dat is waar Code-P West B.V. zich in onderscheid.
Wij maken gebruik van 5 assige freesmachines en een modern cad cam systeem voor het maken van de meest uit een lopende producten. Enkele stuks maar ook grotere serie’s kunnen wij desgewenst met een meetrapport leveren.
Haas VF 2 SS - CNC Frezen

Machinepark

Complexe CNC Freesdelen

Complexe freesdelen

CNC Frezen

Haas VF 2 SS - CNC Frezen

Haas VF 2 SS  ( 2 stuks )

Bereik X 750 mm Y 400 mm Z 500 mm
Tafel 900 mm x 350 mm
Max belasting 1350 kg
Spindel snelheid 12000 rpm
Tools 25

Haas DT1 - CNC Frezen

Haas  DT 1 SS

Bereik X 500 mm Y 400 mm Z 390 mm
Tafel 660 mm x 380 mm
Max belasting 110 kg
Spindel snelheid 12000 rpm
Tools 20

5-Assig CNC Frezen

Haas UMC 750SS - CNC Frezen

Haas UMC 750

Bereik  X  760 mm Y  500 mm Z  500 mm
Trunnion tafel afmeting  630 x 500 mm
B-as (kantel) +110deg. tot -35deg.
C-as (rond tafel) 360deg.
Werkstuk hoogte 400 mm
Belasting 300 kg
Spindel snelheid 12000 rpm
Tools 40

Haas VF 2 SS - CNC Frezen

Haas VF 2 SS

Bereik X 750 mm Y 400 mm Z 500
Trunnion tafel afmeting: rond 160  mm
B-as (kantel) +110deg. tot -35deg.
C-as (rond tafel) 360deg.
Werkstuk groote:
rond 445 mm, hoog 300 mm
Belasting 35 kg
Spindel snelheid 12000 rpm
Tools 25

5-Assig CNC Frezen met robotbelading

Haas VF 2 SS - CNC Frezen

Haas VF 2 SS

Bereik X 750 mm Y 400 mm Z 500
trunnion Tafel afmeting: rond 160  mm
B-as (kantel) +110deg. tot -35deg.
C-as (rond tafel) 360deg.
werkstuk groote:
rond 445 mm hoog 300 mm
capaciteit 35 kg
spindel snelheid 12000 rpm
Tools 25

Kawasaki robotarm
+ automatische aan en afvoer

Capaciteit  200×100
max 3 KG.
